-86°C Self-Cascade System
WDF-86V58 58L Under-Counter -86°C Ultra Low Temperature Freezer
58L capacity. Compact 58L under-counter ultra-low temperature freezer.
View Details-40°C to -86°C · 58L to 838L · 3 refrigeration systems
Ultra Low Temperature Freezers (-86°C ULT Freezers)
WinHyCare designs and supplies -86°C ultra low temperature freezers for laboratories, biobanks, hospitals and pharmaceutical R&D, usually run as a -80°C lab freezer. The range covers dual-system, cascade and self-cascade refrigeration, from a 58L under-counter unit to 838L upright cabinets, with 1°C set-point control, USB temperature-data download and battery-backed alarms. Prices are quoted per model, with delivery, installation and annual maintenance across India coordinated from our Hyderabad service centre.
Get a ULT freezer quote
-86°C ULT Freezer Models and Specifications
Sorted by capacity. Box counts and energy figures are listed where the model specification states them; open a model for dimensions, pull-down and hold-over times.
| Model | System | Capacity | Compressors | 2-inch boxes | Energy | Range | Price |
|---|---|---|---|---|---|---|---|
| | Self-cascade | 58L | n/a | n/a | n/a | -40°C to -86°C | On request |
 | Self-cascade | 188L | n/a | n/a | n/a | -40°C to -86°C | On request |
 | Cascade | 340L | n/a | n/a | n/a | -40°C to -86°C | On request |
 | Self-cascade | 340L | 1 | 192 | 13.09 kWh/24h | -40°C to -86°C | On request |
 | Dual system | 408L | 2 | n/a | n/a | -40°C to -86°C | On request |
 | Cascade | 408L | n/a | n/a | n/a | -40°C to -86°C | On request |
 | Self-cascade | 408L | 1 | 288 | 12.82 kWh/24h | -40°C to -86°C | On request |
 | Dual system | 588L | 2 | n/a | n/a | -40°C to -86°C | On request |
 | Cascade | 588L | n/a | n/a | n/a | -40°C to -86°C | On request |
 | Cascade | 588L | 2 | 400 | 16.02 kWh/24h | -40°C to -86°C | On request |
 | Dual system | 600L | 2 | n/a | n/a | -40°C to -86°C | On request |
 | Cascade | 688L | n/a | n/a | n/a | -40°C to -86°C | On request |
| | Cascade | 728L | n/a | n/a | n/a | -40°C to -86°C | On request |
 | Cascade | 728L | 2 | 504 | 23.44 kWh/24h | -40°C to -86°C | On request |
 | Dual system | 838L | 2 | n/a | n/a | -40°C to -86°C | On request |
 | Cascade | 838L | n/a | n/a | n/a | -40°C to -86°C | On request |
 | Cascade | 838L | 2 | 600 | 19.98 kWh/24h | -40°C to -86°C | On request |
Choosing a -80°C Laboratory Deep Freezer: Dual, Cascade or Self-Cascade
The refrigeration system decides what happens when a compressor fails, how much power the freezer draws and which sizes are available. Our ULT freezer buying guide compares them in detail.
- Dual-system -86°C freezers → Two independent refrigeration systems; if one fails, the other holds the cabinet at -70°C. 408L to 838L.
- Cascade -86°C freezers → Two-stage cascade refrigeration with HC refrigerant. 340L to 838L.
- Self-cascade -86°C freezers → Single compressor with mixed refrigerant. 58L under-counter to 408L.
All Ultra Low Freezer Models
-86°C Self-Cascade System
WDF-86V188E 188L Self-Cascade -86°C Ultra Low Temperature Freezer
188L capacity. Compact self-cascade ultra-low freezer with single compressor design.
View Details -86°C Cascade System
WDF-86V340II 340L Cascade -86°C Ultra Low Temperature Freezer
340L capacity. Ultra-low temperature freezer with cascade refrigeration system.
View Details -86°C Self-Cascade System
WDF-86V340E 340L Self-Cascade -86°C Ultra Low Temperature Freezer
340L capacity. New-Generation 340L self-cascade -86°C ultra-low freezer.
View Details -86°C Dual System
WDF-86V408D 408L Dual System -86°C Ultra Low Temperature Freezer
408L capacity. Dual system ultra-low temperature freezer with double security.
View Details -86°C Cascade System
WDF-86V408 408L Cascade -86°C Ultra Low Temperature Freezer
408L capacity. 408L cascade system ultra-low temperature freezer with HC refrigerant for 50% energy saving.
View Details -86°C Self-Cascade System
WDF-86V408E 408L Self-Cascade -86°C Ultra Low Temperature Freezer
408L capacity. New-Generation 408L self-cascade -86°C ultra-low freezer.
View Details -86°C Dual System
WDF-86V588D 588L Dual System -86°C Ultra Low Temperature Freezer
588L capacity. Dual system ultra-low temperature freezer with double security.
View Details -86°C Cascade System
WDF-86V588 588L Cascade -86°C Ultra Low Temperature Freezer
588L capacity. 588L cascade system ultra-low freezer with energy-efficient HC refrigerant.
View Details -86°C Cascade System
WDF-86V588E 588L Cascade -86°C Ultra Low Temperature Freezer
588L capacity. New-Generation 588L cascade -86°C ultra-low freezer.
View Details -86°C Dual System
WDF-86V600L 600L Smart Dual Cooling -86°C Ultra Cold Laboratory Freezer
600L capacity. Smart ultra-cold laboratory freezer with dual cooling and 13.
View Details -86°C Cascade System
WDF-86V688 688L Cascade -86°C Ultra Low Temperature Freezer
688L capacity. 688L cascade system ultra-low temperature freezer.
View Details -86°C Cascade System
WDF-86V728 728L Cascade -86°C Ultra Low Temperature Freezer
728L capacity. 728L cascade system ultra-low freezer for large-scale biomedical and pharmaceutical storage applications.
View Details -86°C Cascade System
WDF-86V728E 728L Cascade -86°C Ultra Low Temperature Freezer
728L capacity. New-Generation 728L cascade -86°C ultra-low freezer.
View Details -86°C Dual System
WDF-86V838D 838L Dual System -86°C Ultra Low Temperature Freezer
838L capacity. Large-capacity dual system ultra-low temperature freezer with double security.
View Details -86°C Cascade System
WDF-86V838 838L Cascade -86°C Ultra Low Temperature Freezer
838L capacity. Largest capacity cascade system ultra-low freezer at 838L.
View Details -86°C Cascade System
WDF-86V838E 838L Cascade -86°C Ultra Low Temperature Freezer
838L capacity. New-Generation 838L cascade -86°C ultra-low freezer, the largest in the range.
View DetailsWhere ULT Freezers Are Used
- Laboratory cold storageCell lines, reagents, enzymes and research samples.
- Ultra-cold vaccine storageVaccines stored at -60°C to -80°C (WHO ultra-cold chain).
- Blood centresLong-term frozen plasma and components.
- Pharmaceutical storageBiologics, retained samples and clinical material.
- HospitalsTissue, IVF and hospital research labs.
- -40°C plasma freezerWhen -40°C is enough.
Tenders, Delivery and Service
Research institutes, medical colleges and hospitals can request model-wise datasheets and quotations for tenders: capacity, temperature range, refrigeration system, alarm list, data export and power requirements. Units are certified to ISO 9001/13485/14001 standards and designed to meet NABH/NBTC requirements. Installation, commissioning and annual maintenance across India are coordinated from our Hyderabad service centre.
Tenders and procurement · Delivery across India
City pages: ultra low freezers in Hyderabad, Delhi NCR and Bangalore.
ULT Freezer FAQs
What is an ultra low temperature freezer?
An ultra low temperature (ULT) freezer is a laboratory freezer that reaches about -80°C or colder. WinHyCare ULT freezers are adjustable from -40°C to -86°C in 1°C steps and are used for biological samples, reagents, enzymes, tissue and frozen blood components.
What is the difference between a -80°C freezer and a -86°C freezer?
They are usually the same equipment. -86°C is the lowest temperature the freezer can reach; -80°C is the typical working set point. The margin below the set point helps the cabinet recover after door openings. Our ULT buying guide covers set-point choice and energy use.
Should I buy a dual-system, cascade or self-cascade ULT freezer?
Dual-system models suit collections where a single compressor failure is unacceptable, because the second system holds -70°C. Cascade models cover the large-capacity range. Self-cascade models use one compressor and include the compact 58L under-counter unit and the lowest-energy model in our range (WDF-86V408E, 12.82 kWh/24h).
What capacities are available?
From the 58L under-counter WDF-86V58 to 838L upright cabinets. New-Generation models list storage in 2-inch boxes, from 192 boxes (340L) to 600 boxes (838L).
Do the freezers keep temperature records?
Yes. Models have USB temperature-data download, high/low temperature and power-failure alarms with battery backup, and remote alarm contacts on many models, so logs can be archived for audits.
What is the price of a ULT freezer?
We quote per model, quantity and delivery city, including installation and optional annual maintenance. Send the capacity and configuration you need.
